Exploring Current Transformer Applications (Part 2)

When choosing the burden resistor, the engineer can create any output voltage per amp, as long as it doesn't saturate the core. Core saturation level is an important consideration when specifying current transformers. The maximum volt-microsecond product specifies what the core can handle without saturating. The burden resistor is one of the factors controlling the output voltage. There's a limit to the amount of voltage that can be achieved at a given frequency. Since frequency = 1/cycle period, if the frequency is too low (cycle period too long) so that voltage-time product exceeds the core's flux capacity, saturation will occur. The flux that exists in a core is proportional to the voltage times cycle period. Most specifications provide a maximum volt-microsecond product that the current transformer can provide across the burden resistor. Exceeding this voltage with too large a burden resistor will saturate the transformer and limit the voltage.

What happens if the burden resistor is left off or opens during operation? The output voltage will rise trying to develop current until it reaches the saturation voltage of the coil at that frequency. At that point, the voltage will cease to rise and the transformer will add no additional impedance to the driving current. Therefore, without a burden resistor, the output voltage of a current transformer will be its saturation voltage at the operating frequency.

There are factors in the current transformer that affect efficiency. For complete accuracy, the output current must be the input current divided by the turns ratio. Unfortunately, not all the current is transferred. Some of the current isn't transformed to the secondary, but is instead shunted by the inductance of the transformer and the core loss resistance. Generally, it's the inductance of the transformer that contributes the majority of the current shunting that detracts from the output current. This is why it's important to use a high-permeability core to achieve the maximum inductance and minimize the inductance current. Accurate turns ratio must be maintained to produce the expected secondary current and the expected accuracy. Fig. 2 shows the current transformed is smaller than the input current by:

ITRANSFORMED=IINPUT-ICORE-jIMAG (1)

What about the effect the transformer will have on the current it's monitoring? This is where the term burden enters the picture. Any measuring device alters the circuit in which it measures. For instance, connecting a voltmeter to a circuit causes the voltage to change from what it was before the meter was attached. However minuscule this effect may or may not be, the voltage you read isn't the voltage that existed before attaching the meter. This is also true with a current transformer. The burden resistor on the secondary is reflected to the primary by (1/N2), which provides a resistance in series with the current on the primary. This usually has minimal effect and is usually only important when you are concerned about the current that would exist when the transformer isn't in the circuit, such as when it's used as a temporary measuring device.

Notice the four loss components in the circuit of Fig. 2. The resistance of the primary loop (PRIDCR), the core loss resistance (RCORE), the secondary DCR (RDCR) is reduced by 1/N2, and the secondary burden resistor RBURDEN is also reduced by a factor of N2. These are losses that affect current source (I). The resistances have an indirect effect on the current transformer accuracy. It's their effect on the circuit that they are monitoring that alters its current. The primary dc resistance (PRIdcr) and the secondary DCR/N2 (RDCR/N2) don't detract from the Iinput that is read or is affecting the accuracy of the actual current reading. Rather, they alter the current from what it would be if the current transformer weren't in the circuit. With the exception of the burden resistor, these loss resistors are the components that contribute to the loss in the transformer and heating.

This wasted energy is usually small compared with the power in the circuit it's monitoring. Usually, the design of the transformer and choice of the burden resistor will be within the maximum energy loss the end user can allow. As battery-operated devices come into wider use and power consumption contributes to the energy crisis — even this power may be of concern. Under these circumstances, it may require special design attention to power consumption.

Current transformers are an efficient way to measure current. Since the burden resistor is reflected to the primary by 1/N2, the resistance seen in the circuit being monitored can be very small. This allows a larger voltage to be created on the output with minimal effect on the circuit being measured. A simpler and lower-cost method to measure current is to use a sense resistor connected in series with the current. However, this method can only be used when power consumption is of secondary concern. With the more frequent use of battery-powered devices and the prevailing need to reduce power consumption, the extra expense of a current transformer can soon be recovered with use. Also, with high current or when a voltage of any magnitude is required, a sense resistor would be impractical.

Read more...

Exploring Current Transformer Applications (Part 1)

For a variety of applications, using current transformers is an efficient way to sense current with minimum insertion loss.

Current transformers can perform circuit control, measure current for power measurement and control, and perform roles for safety protection and current limiting. They can also cause circuit events to occur when the monitored current reaches a specified level. Current monitoring is necessary at frequencies from the 50 Hz/60 Hz power line to the higher frequencies of switchmode transformers that range into the hundreds of kilohertz.

The object with current transformers is to think in terms of current transformation rather than voltage ratios. Current ratios are the inverse of voltage ratios. The thing to remember about transformers is that Pout = (Pin — transformer power losses). With this in mind, let's assume we had an ideal loss-less transformer in which Pout = Pin. Since power is voltage times current, this product must be the same on the output as it is on the input. This implies that a 1:10 step-up transformer with the voltage stepped up by a factor of 10 results in an output current reduced by a factor of 10. This is what happens on a current transformer. If a transformer had a one-turn primary and a ten-turn secondary, each amp in the primary results in 0.1A in the secondary, or a 10:1 current ratio. It's exactly the inverse of the voltage ratio — preserving volt times current product.

How can we use this transformer and knowledge to produce something useful? Normally, an engineer wants to produce an output on the secondary proportional to the primary current. Quite often, this output is in volts output per amp of primary current. The device that monitors this output voltage can be calibrated to produce the desired results when the voltage reaches a specified level.

A burden resistor connected across the secondary produces an output voltage proportional to the resistor value, based on the amount of current flowing through it. With our 1:10 turns ratio transformer that produces a 10:1 current ratio, a burden resistor can be selected to produce the voltage we want. If 1A on the primary produces 0.1A on the secondary, then by Ohm's law, 0.1 times the burden resistor will result in an output voltage per amp.

Many voltage transformers have adjusted ratios that produce the desired output voltage and compensate for losses. The turns-ratios or actual turns aren't the primary concern of the end-user. Only the voltage output and possibly regulation and other loss parameters may be of concern. With current transformers, the user must know the current ratio to use the transformer. The knowledge of amps in per amps out is the basis for use of the current transformer. Quite often, the end users provide the primary with a wire through the center of the transformer. They must know what secondary turns are to determine what their output current will be. Generally, in catalogues, the turns of the transformers are provided as a specification for use.

With this knowledge, the user can choose the burden resistor to produce their desired output voltage. The output current of 0.1A for a 1A primary on the 1:10 turns ratio transformer will produce 0.1 V/A across a 1Ω burden resistor, 1V per amp across a 10Ω burden and 10V per amp across a 100Ω burden resistor.

Fig. 1 shows an ideal transformation ratio. In this analysis, the secondary dc resistance (RDCR) doesn't become part of the calculation. When considering the secondary current, only the actual current affects V. How well that current can be determined controls the accuracy of the prediction of V. The secondary dc resistance is best analyzed by reflecting it to the primary by RDCR/N2.



Read more...

Current Tranformers (Part-3 Finish)

Note:

General

CTs should be specified as follows:

RATIO: input / output current ratio

VA: total burden including pilot wires.

CLASS: Accuracy required for operation

DIMENSIONS: maximum & minimum limits

Metering CTs In general, the following applies:
CLASS • 0.1 or 0.2 for precision measurements
• 0.5 for high grade kilowatt hour meters for commercial grade kilowatt hour meters
• 3 for general industrial measurements
• 3 or 5 for approximate measurements
BURDEN (depending on pilot lead length) • Moving iron ammeter 1-2VA
• Moving coil rectifier ammeter 1-2.5VA
• Electrodynamic instrument 2.5-5VA
• Maximum demand ammeter 3-6VA
• Recording ammeter or transducer 1-2.5VA

Protection CTs In addition to the general specification required for CT design, protection CT’s require an Accuracy Limit Factor (ALF). This is the multiple of rated current up to which the CT will operate while complying with the accuracy class requirements.
In general the following applies:
• Instantaneous overcurrent relays & trip coils - 2.5VA Class 10P5
• Thermal inverse time relays - 7.5VA Class 10P10
• Low consumption Relay - 2.5VA Class 10P10
• Inverse definite min. time relays (IDMT) overcurrent - 15VA Class 10P10/15
• IDMT Earth fault relays with approximate time grading - 15VA Class 10P10
• IDMT Earth fault relays with phase fault stability or accurate time grading required - 15VA Class 5P10

Class X CTs Class X CTs are special CTs used mainly in balanced protection systems (including restricted earth fault) where the system is sensitively dependent on CT accuracy. Further to the general CT specifications, the manufacturer needs to know:
• Vkp - Voltage knee point
• Io - Maximum magnetising current at Vkp
• Rs - Maximum resistance of the secondary winding

Read more...

Current Tranformers (Part-2)

Preferred primary and secondary current ratings [and therefore ratios], classes, burdens and accuracy limit factors are defined in BS3938 and other comparable national standards, together with other minimum performance requirements, physical construction requirements, etc.

It should be remembered when using a CT that where there are two or more devices to be operated by the secondary winding, they must be connected in series across the winding. This is exactly the opposite of the method used to connect two or more loads to be supplied by a voltage or power transformer where the devices are paralleled across the secondary winding.

With a CT, an increase in the burden will result in an increase in the CT secondary output voltage. This is automatic and necessary to maintain the current to the correct magnitude. Conversely, a reduction in the burden will result in a reduction in the CT secondary output voltage.
This rise in secondary voltage output with an increase in burden means that, theoretically, with infinite burden as is the case with the secondary load open circuit, an infinitely high voltage appears across the secondary terminals. For practical reasons this voltage is not infinitely high, but can be high enough to cause a breakdown in the insulation between primary and secondary windings or between either or both windings and the core.
For this reason, primary current should never be allowed to flow with no load or with a high resistance load connected across the secondary winding. When considering the application of a CT it should be remembered that the total burden imposed on the secondary winding is not only the sum of the burden(s) of the individual device(s) connected to the winding but that it also includes the burden imposed by the connecting cable and the resistance of the connections.
If, for example, the resistance of the connecting cable and the connections is 0.1 ohm and the secondary rating of the CT is 5A, the burden of the cable and connections (RI2) is 0.1 x 5 x 5 = 2.5VA. This must be added to the burden(s) of the connected device(s) when determining whether the CT has an adequately large burden rating to supply the required device(s) and the burden imposed by the connections.
Should the burden imposed on the CT secondary winding by the connected device(s) and the connections exceed the rated burden of the CT the CT may partly or fully saturate and therefore not have a secondary current adequately linear with the primary current.
The burden imposed by a given resistance in ohms [such as the resistance of a connecting cable] is proportional to the square of the rated secondary current. Therefore, where long runs of cable between CT and the connected device(s) are involved, the use of a 1A secondary CT and a 1A device rather than 5A will result in a 25-fold reduction in the burden of the connecting cables and connections.
All burden ratings and calculations are at rated secondary current. Because of the foregoing, when a relatively long [more than a very few metres] cable run is required to connect a CT to its burden [such as a remote ammeter] a calculation should be made to determine the cable burden. This is proportional to the “round trip” resistance, i.e. twice the resistance of the length of twin cable used. Cable tables provide information on the resistance values of different sizes of conductors at 20o C per unit length. The calculated resistance is then multiplied by the square of the CT secondary current rating [25 for 5A, 1 for 1A]. If the VA burden as calculated by this method and added to the rated burden(s) of the device(s) to be driven by the CT exceeds the CT burden rating, the cable size must be increased [to reduce the resistance and thus the burden] or a CT with a higher VA burden rating must be used, or a lower CT secondary current rating [with matching change in the current rating of the device(s) to be driven] should be substituted.

Read more...

Current Tranformers (Part-1)

A current transformer is a transformer, which produces in its secondary winding a current, which is proportional to the current flowing in its primary winding. The secondary current is usually smaller in magnitude than the primary current.

The principal function of a CT is to produce a proportional current at a level of magnitude, which is suitable for the operation of measuring or protective devices such as indicating or recording instruments and relays.

The rated secondary current is commonly 5A or 1A, though lower currents such as 0.5A are not uncommon. It flows in the rated secondary load, usually called the burden, when the rated primary current flows in the primary winding.
The primary winding can consist merely of the primary current conductor passing once through an aperture in the current transformer core or it may consist of two or more turns wound on the core together with the secondary winding.
These are two basic CT types. The first is commonly called a “ring” type CT as the core is usually annular, but in some cases it may be square or rectangular in shape. The second is usually known as a “wound primary” type CT.
The primary and secondary currents are expressed as a ratio such as 100/5. With a 100/5 ratio CT, 100A flowing in the primary winding will result in 5A flowing in the secondary winding, provided the correct rated burden is connected to the secondary winding. Similarly, for lesser primary currents, the secondary currents are proportionately lower.
It should be noted that a 100/5 CT would not fulfil the function of a 20/1 or a 10/0.5 CT as the ratio expresses the current rating of the CT, not merely the ratio of the primary to the secondary currents.
The extent to which the secondary current magnitude differs from the calculated value expected by virtue of the CT ratio is defined by the [accuracy] “Class” of the CT. The greater the number used to define the class, the greater the permissible “current error” [the deviation in the secondary current from the calculated value].
Except for the least accurate classes, the accuracy class also defines the permissible phase angle displacement between primary and secondary currents. This latter point is important with measuring instruments influenced both by magnitude of current and by the phase angle difference between the supply voltage and the load current, such as kWh meters, wattmeter’s, var meters and power factor meters.
Common burden ratings are 2.5, 5, 10, 15 and 30VA.
Current transformers are usually either “measuring” or “protective” types, these descriptions being indicative of their functions. The principal requirements of a measuring CT are that, for primary currents up to 120% or 125% of the rated current, its secondary current is proportional to its primary current to a degree of accuracy as defined by its “Class” and, in the case of the more accurate types, that a specified maximum phase angle displacement is not exceeded.
A desirable characteristic of a measuring CT is that it should “saturate” when the primary current exceeds the percentage of rated current specified as the upper limit to which the accuracy provisions apply. This means that at these higher levels of primary current the secondary current is less than proportionate. The effect of this is to reduce the extent to which any measuring device connected to the CT secondary is subjected to current overload.
On the other hand the reverse is required of the protective type CT, the principal purpose of which is to provide a secondary current proportional to the primary current when it is several, or many, times the rated primary current. The measure of this characteristic is known as the “Accuracy Limit Factor” (A.L.F.). A protection type CT with an A.L.F. of 10 will produce a proportional current in the secondary winding [subject to the allowable current error] with primary currents up to a maximum of 10 times the rated current.
